Current Injection Tester

Current Injection Tester
Current Injection Tester
Product Code : 19
Product Description

Backed by adroit professionals & ultramodern infrastructure, we are engaged in manufacturing and exporting Current Injection Tester. These testing apparatuses are portable and demanded among our clients due to their accurate reading and easy operation. Immensely used for testing and calibration of Bi-metals relays, CT's and heat run, these injection test sets are delivered to our clients within specified time frame.  To offer flawless range, we duly check Current Injection Tester on diverse quality parameters.

Further Details:

Current Injection Test Sets are specially designed c. Each unit is designed as per the customers specification. These units are air cooled/oil cooled depending upon capacity and duty cycle. Normally the primary current injection test sets are designed for 15 minutes On and 30 minutes Off duty cycle and loading transformer for continuous duty used for temperature rise test of Bus dust, Bus bar and joints, etc.

Special Feature

  • Compact in size
  • Special insulating paper is used for transformer winding
  • Guaranteed for one year against manufacturing defects
  • Sufficient after sales service

Brief technical details

Step down transformer

A double wound transformer is used for supplying high current at low voltage for testing

Current control

A step less Auto Transformer is used for controlling output current from Zero to Maximum

Input Voltage

230/415 Volts single/two/three phase 50Hz AC supply

Output voltage ranges

As per requirement

Output Current

Upto 25000 Amps

Capacity

Upto 500 kVA

Output Voltage Range

15 Minutes On-30 Minutes Off in case of Primary Injection Test Set and continuous in case of Loading Transformer

Termination

The output is brought out on suitable Bus Bar/Terminals

Protection

On-Off switch with fuse is provided to protect the unit against short circuit, push button to actual and cut of output overload protection

Housing

Each unit is housed in a MS sheet body, supported with angle iron frame. The oil cooled models are housed in convenient MS tank and the control panel is on the tank or as per requirements

Optional Accessories

Voltmeter

Time Interval Meter/ Timer

Rubber (HORF) cable

Zero start interlocking with by-pass switch

Computer Interface (Measurement/Control)

External Timer Arrangement
