DC High Voltage Tester

DC High Voltage Tester
DC High Voltage Tester
Product Code : R-15
Product Description

Being a quality oriented company, we are acknowledged amongst the top-leading manufacturers and exporters of DC High Voltage Tester.  Broadly used to check the condition of underground cables at high voltage, we are offering these instruments to our clients in diverse configurations. Suitable to avoid breakdown situation in diverse electrical applications, our test set is appreciated for its light weight, compact size and easy operation. Apart from this, clients can buy DC High Voltage Tester from us at unbeatable prices.

Introduction:

Due to fast industrial growth, underground cables are being laid everywhere. Normally the testing of these cables at site is done with the help of meggar which dose not give clear position of the fault in the cable. 'RE' portable DC,

Special Features:

  • Compact size, light in weight
  • Easy to operate
  • Special insulating material used for transformer insulation
  • Guaranteed for one year against manufacturing defects
  • Efficient after sales service
Brief Technical Detail:

Input 220/230 Volts Single Phase 50Hz. AC supply
Output voltage 10 - 150 KV
KVA 10 W - 150 W
Cooling Naturally Air Cooled
Output Voltage Control Stepless
Rating Continuous for testing duty

  • HT Cable: The equipment is supplied with ten meters long copper braided H.T. cable with HT plug and socket. The braiding remains on earth potential.
  • LT Cable: For input supply ten meters long 3 core cable is provided.
  • Zero Start Interlocking: This is to ensure that the H.T. shall not actuate if the voltage control knob is not at zero position.
  • Earth Interlocking: If proper earth is not connected the HT shall not actuate.
  • Auto Discharging Arrangement : The equipment consists of automatic cable discharging arrangement.
  • Socket: H.T. plug and socket has been specially developed by us with automatic earthing arrangement.
