Oil BDV Test Set
50000.00 - 100000.00 INR/Set
Product Details:
- Product Type Transformer Oil BDV Test Set
- Material MS
- Measuring Voltage Range Up to 800kV and 250mA Volt (v)
- Operating Temperature 0-50 Deg. C Celsius (oC)
- Frequency (MHz) 50 Hz Hertz (HZ)
- Insulation Box Output Voltage on HV electrodes with Oil cup in between
- Protection System Over Voltage , Over load and earth fault protection
- Click to View more
X
Oil BDV Test Set Price And Quantity
- 01 Set
- 50000.00 - 100000.00 INR/Set
Oil BDV Test Set Product Specifications
- 0-50 Deg. C Celsius (oC)
- 50 Hz Hertz (HZ)
- Transformer Oil BDV Test Set
- Up to 800kV and 250mA Volt (v)
- Depends upon the kV rating required by Customer
- Output Voltage on HV electrodes with Oil cup in between
- RAL-7032
- MS
- Depends upon the kV rating required by Customer
- Over Voltage , Over load and earth fault protection
- 12 Months from manufacturing
- Depends upon the kV rating required by Customer Kilograms (kg)
Oil BDV Test Set Trade Information
- Delhi
- 3 Set Per Year
- 8 Week
- Yes
- Contact us for information regarding our sample policy
- Bubble Wrap or Wooden packing or As required by the customer
- All India
- ISO : 9001 : 2008 ISO : 14001 and OHSAS:18000
Product Description
DESCRIPTION :-
Automatic Oil Test set is designed for testing the dielectric strength of insulating oil as per IS:335.The unit develops high voltage between electrodes immersed in oil under test as per IS:6792. In addition to the test preparation in detail, the set is automatically governed by a trouble-free Microprocessor. These features enable user to operate the equipment with a single touch of the Feather Touch Button. The results can be viewed on the backlit LCD display or can be printed as a hard copy. The results can be summarized at a later stage because of the presence of memory function for the tests conducted stored in the memory.
Available in three Models
(i) Motorized Oil Test Set (MOTS).
(ii) Semi-Automatic Oil Test Set (SAOTS).
(iii) Fully Automatic Oil Test Set (AOTS).
Features :-
- Compact size & portable design
- Build in safety arrangements
- Easy to operate
- Auto / Manual Selectable
- One Touch Operation
- On Screen LCD & Printer Facility on the Unit
- Real Time Clock & Date
- 9999 record Memory
- Computer Connectivity through USB/RS232
- Operator code programmable
- Rate of rise of voltage 0.5kV/sec to 5.0 kV/sec
Accessories :-
Standard Accessories
Oil Pot, Go No Go gauge, Round ELCTRODE
Optional
-
Mushroom, Cylindrical
-
Earthing cable
-
High Voltage Calibrator, Sphere Oil Cup, Oil Sampling Bottle
Technical Specifications :-
|
| Technical Details of all the Three Models of OIL BDV TEST SET | |||
|
|
|
|
|
|
| Sr. No. | Parameters | Motorized Oil Test Set | Semi Automatic Oil Test Set | Fully Automatic oil Test Set |
| 1 | Rate of Rise | 2KV/sec | 2KV/sec | 0.5 to 5KV/ Sec |
| 2 | Operation | Individual ( Every after every reading you have to reset) | One touch Operation | One Touch Operation |
| 3 | Operation | Only one | Preset 06 nos | Setable 4 -9 Operations |
| 4 | Standard Deviation | Manual | No | Yes |
| 5 | Average Calculation | Manual | Yes | Yes |
| 6 | Memory | Individual Reading (Only for current test) | Present test reset / Power Off | Previous 9999 Tests |
| 7 | Printout | No | No | Yes |
| 8 | Computer Compatibality | No | No | Yes RS232 |
| 9 | EMI/EMC Protection | No | Yes | Yes |
| 10 | Safety as per IEC61010 | No | Yes | Yes |
| 11 | Display | Analog/Digital | LCD 1" X 1" Alpha Numeric | Yes 16 X 2 character alpha numeric |
